Beacon YYW-10000A Turbo Balancing Machine Industrial Portable Dynamic Balance Equipment

The YYW series is a universal hard-drive horizontal double-sided dynamic balancing machine driven by a universal coupling. The equipment model covers the measurement range from a few kilograms to more than 50 tons. This series of equipment is highly suitable for the dynamic balance measurement of various parts with regular or irregular workpiece shapes, smooth surface parts or spurs on the workpiece surface, fan impellers and centrifuge drums with large rotational inertia and air damping, and is widely used in Motors, generators, fans, engines, agricultural machinery, textile machinery, chemicals, woodworking machinery, paper machinery and other industries can be balanced on one side, two sides and multiple calibration surfaces, suitable for shafts, discs and centers of gravity Extend the rotor. It has the advantages of high efficiency, accurate accuracy, intuitive display and reliable quality.

Range of workpiece weight (kg)：300-10000

Max. diameter of workpiece (mm)：Φ 2400

Distance between two bearing (mm)：340-5100

Bed frame length (mm)：3400 (Two-section bed)

Support shaft diameter (mm)：Φ 50-200, Φ 200-360

Balancing speed (r/min)：253/435/708/1140

The minimum speed of the device to measure(r/min)：80

Minimum residual imbalance：≤1gmm/kg

Imbalance reduction rate (%)：≥90%

Motor power：45Kw

Universal joint torque：300Nm and 2500Nm (two sets)

Work voltage：AC 3 phase 380V 50/60Hz

*Test data from Beacon laboratory
